Material
• Casted Co-Cr alloy that has a long record of
clinical success with increased material strength
Neck:
• Neck angle incorporate a 135 degree which is highly
polished to decrease grinding caused by the friction
between stem neck and UHMWPE component
• Standard Offsets
• Reduced proportionate Neck Geometry to increase Range
of motion
Design
• Biplanar taper without collar convert the longitudinal
shear force to lateral compression force
• Highly polished surface reduces the shear force between
prosthesis and the bone cement
• Smooth prosthesis edge avoids stress concentration and the
cutting the bone cement
• Collarless
• Head 12/14 taper
Size
• 7 available sizes with length starting from 130mm to 155mm
